Application: LED Drive Power Supply, Medical Power Supply
Features1: Glass Passivated Chip
Features2: Low Forward Voltage Drop
Features3: Ideal for Printed Circuit Board
Features4: High Surge Current Capability
Transport Package: Plastic Package
Application: LED Drive Power Supply, Medical Power Supply
Features1: Glass Passivated Chip
Features2: Low Forward Voltage Drop
Features3: Ideal for Printed Circuit Board
Features4: High Surge Current Capability
Transport Package: Plastic Package
Basic Info.
Model NO. | LAN9512 | Specification | 28-pin QFN 28-pin SOIC |
Origin | Guangdong, China | Production Capacity | 10000 Pieces/Day |
Part Name
High-Performance USB 2.0 Hub and 10/100 Ethernet Controller LAN9512
Features
USB Hub
- Fully compliant with Universal Serial Bus Specification Revision 2.0
- HS (480 Mbps), FS (12 Mbps), and LS (1.5 Mbps) compatible
- Two downstream ports, one upstream port
- Port mapping and disable support
- Port Swap: Programmable USB diff-pair pin location
- PHY Boost: Programmable USB signal drive strength
- Select presence of a permanently hardwired USB peripheral device on a port by port basis
- Advanced power saving features
- Downstream PHY goes into low power mode when port power to the port is disabled
- Full Power Management with individual or ganged power control of each downstream port.
- Integrated USB termination Pull-up/Pull-down resistors
- Internal short circuit protection of USB differential signal pins
Target Applications
• Desktop PCs
• Notebook PCs
• Printers
• Game Consoles
• Embedded Systems
• Docking Stations
