Application: LED Drive Power Supply, Medical Power Supply
Features1: Glass Passivated Chip
Features2: Low Forward Voltage Drop
Features3: Ideal for Printed Circuit Board
Features4: High Surge Current Capability
Transport Package: Plastic Package
Application: LED Drive Power Supply, Medical Power Supply
Features1: Glass Passivated Chip
Features2: Low Forward Voltage Drop
Features3: Ideal for Printed Circuit Board
Features4: High Surge Current Capability
Transport Package: Plastic Package
Basic Info.
Model NO. | TI1-TPS7A4901 | Specification | MSOP-8 |
Origin | Guangdong, China | Production Capacity | 10000 Pieces/Day |
Part Name
+36V, +150mA, Ultralow-Noise, Positive LINEAR REGULATOR TI1-TPS7A4901
FEATURES
• Input Voltage Range: +3V to +36V
• Noise:
- 12.7mVRMS (20Hz to 20kHz)
- 15.4mVRMS (10Hz to 100kHz)
• Power-Supply Ripple Rejection:
- 72dB (120Hz)
- ≥ 52dB (10Hz to 400kHz)
• Adjustable Output: +1.194V to +33V
• Output Current: 150mA
• Dropout Voltage: 260mV at 100mA
• Stable with Ceramic Capacitors ≥ 2.2mF
• CMOS Logic-Level-Compatible Enable Pin
• Built-In, Fixed, Current-Limit and Thermal Shutdown Protection
• Available in High Thermal Performance MSOP-8 PowerPAD™ Package
• Operating Tempature Range: -40°C to +125°C
APPLICATIONS
• Supply Rails for Op Amps, DACs, ADCs, and Other High-Precision Analog Circuitry
• Audio
• Post DC/DC Converter Regulation and Ripple Filtering
• Test and Measurement
• RX, TX, and PA Circuitry
• Industrial Instrumention
• Base Stations and Telecom Infrastrucure
