Operational Amplifiers,Single Supply 3.0 V to 44 V,Low Power
Encapsulation Structure: Chip Transistor
Application: LED Drive Power Supply, Medical Power Supply
Certification: RoHS, CE, ISO, CCC
Luminous Intensity: Standard
Color: Black
Structure: to-220f
- Parameters
Encapsulation Structure: Chip Transistor
Application: LED Drive Power Supply, Medical Power Supply
Certification: RoHS, CE, ISO, CCC
Luminous Intensity: Standard
Color: Black
Structure: to-220f
Basic Info.
| Model NO. | MC33174 | Material | Silicon |
| Features1 | Glass Passivated Chip | Features2 | Low Forward Voltage Drop |
| Features3 | Ideal for Printed Circuit Board | Features4 | High Surge Current Capability |
| Transport Package | Plastic Package | Origin | Guangdong, China |
| Production Capacity | 10000 Pieces/Day |
Product Description
Part Name
Operational Amplifiers,Single Supply 3.0 V to 44 V,Low Power MC33174
Features
1.Low Supply Current: 180 A (Per Amplifier)
2.Wide Supply Operating Range: 3.0 V to 44 V or ±1.5 V to ±22 V
3.Wide Input Common Mode Range, Including Ground (VEE)
4.Wide Bandwidth: 1.8 MHz
5. High Slew Rate: 2.1 V/s
6.Low Input Offset Voltage: 2.0 mV
7.Large Output Voltage Swing: −14.2 V to +14.2 V (with ±15 V Supplies)
8.Large Capacitance Drive Capability: 0 pF to 500 pF
9.Low Total Harmonic Distortion: 0.03%
10.Excellent Phase Margin: 60°
11.Excellent Gain Margin: 15 dB
12.Output Short Circuit Protection
13.ESD Diodes Provide Input Protection for Dual and Quad
14.NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP Capable
15.These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
