8-Channel Capacitive Touch Sensor Controller withProximity Detection & Signal Guard
Application: LED Drive Power Supply, Medical Power Supply
Features1: Glass Passivated Chip
Features2: Low Forward Voltage Drop
Features3: Ideal for Printed Circuit Board
Features4: High Surge Current Capability
Transport Package: Plastic Package
- Parameters
Application: LED Drive Power Supply, Medical Power Supply
Features1: Glass Passivated Chip
Features2: Low Forward Voltage Drop
Features3: Ideal for Printed Circuit Board
Features4: High Surge Current Capability
Transport Package: Plastic Package
Basic Info.
| Model NO. | CAP1298 | Specification | PDIP/SOIJ/SOIC/TSSOP |
| Origin | Guangdong, China | Production Capacity | 10000 Pieces/Day |
Product Description
The CAP1298 is a multiple channel capacitive touch
sensor controller. It contains eight (8) individual capacitive
touch sensor inputs with programmable sensitivity
for use in touch sensor applications. Each sensor input
is calibrated to compensate for system parasitic capacitance
and automatically recalibrated to compensate
for gradual environmental changes.
Features
• Eight (8) Capacitive Touch Sensor Inputs
- Programmable sensitivity
- Automatic recalibration
- Calibrates for parasitic capacitance
- Individual thresholds for each button
• Proximity Detection
• Signal Guard
- Isolates the proximity antenna from attenuation
- Reduces system noise sensitivity effects on
inputs
• Multiple Button Pattern Detection
• Power Button Support
• Press and Hold Feature for Volume-like Applications
• 3.3V or 5V Supply
• Analog Filtering for System Noise Sources
• RF Detection and Avoidance Filters
• Digital EMI Blocker
• 8kV ESD Rating on All Pins (HBM)
• Low Power Operation
- 5μA quiescent current in Deep Sleep
- 50μA quiescent current in Standby (1 sensor
input monitored)
- Samples one or more channels in Standby
• SMBus / I2C Compliant Communication Interface
• Available in a 16-pin 3mm x 3mm QFN RoHS
compliant package
• Available in a 14-pin SOIC RoHS compliant package
Applications
• Desktop and Notebook PCs
• LCD Monitors
• Consumer Electronics
• Appliances
